Manual Forming for Taped Axials (Vertical) – MAP 301 V by Estovir Technologies
Overview of Manual Forming for Taped Axials (Vertical) – MAP 301 V
Estovir Technologies introduces the MAP 301 V—a compact, efficient machine designed for manual forming of taped axial components into a vertical V-shape. The unit is ideal for dense PCB assemblies where vertical mounting is essential. It is manually operated through a crank, ensuring complete control and precise lead formation. The MAP 301 V is best suited for medium-volume production across electronics, automotive, and assembly industries.
Key Features of Manual Forming for Taped Axials (Vertical) – MAP 301 V
- High-Speed Output
Delivers an output capacity of up to 18,000 pieces per hour, enabling fast and efficient production. - Precision V-Shape Lead Forming
Forms components into a consistent vertical V-shape, ideal for densely populated circuit boards. - Manual Crank Operation
Manual operation via crank handle provides enhanced control and accuracy without relying on electricity. - Supports Lead Diameters Up to 1.37mm
Accommodates various component sizes, making it highly adaptable to different production requirements. - Compact Machine Design
Its compact footprint (190 mm × 175 mm × 190 mm) saves space on the production floor. - Rugged Industrial Build
Built with durable materials for vibration-free operation and long-term stability in industrial conditions. - Quick Changeover Capability
Allows fast pitch and leg length adjustments, significantly reducing downtime during component changeovers. - Low Maintenance Requirement
Designed with simplicity in mind, requiring minimal maintenance while maintaining high performance.
Why Choose Manual Forming for Taped Axials (Vertical) – MAP 301 V?
The MAP 301 V offers the perfect balance of precision, control, and productivity. Its manual crank operation provides the operator with full control, allowing for fine-tuning and customization during forming. Built with a compact, heavy-duty frame, it supports small-to-mid-scale operations that demand consistency and reliability. Whether you’re handling dense PCBs or varied lead sizes, this machine is engineered to perform.
- Perfect for small spaces and mobile workstations
- Eliminates need for electrical setup
- Ideal for continuous use in industrial environments
- Easy to operate, adjust, and maintain
- Designed by Estovir Technologies for long-term value
Applications of Manual Forming for Taped Axials (Vertical) – MAP 301 V
MAP 301 V is widely used in manufacturing environments that require vertical lead forming:
- Electronics and PCB manufacturing lines
- Automotive electronic assembly units
- Industrial component forming and processing setups
- Consumer electronics and LED-based systems
- Component packaging and reshaping facilities
Product Type Compatibility:
- Axial leaded components in taped form
Automatic Grade:
- Manual (non-electric, fully mechanical)
To further streamline operations, Estovir Technologies offers a complete range of manual and automatic preforming machines to handle different requirements:
- Cut and Bend Machine – Cut and bend of taped radial components up to Dia 0.8mm soft wire.
- De-Taping Machine – Cutting of taped radial components for tape
- Forming for Taped Axials Vertical – Perfect for vertical forming of axials up to Dia 1.37mm
- Forming for Taped Axials Horizontal– Suitable for horizontal forming of taped axials up to Dia 1.37mm
Each of these machines is engineered for high performance and supported by Estovir’s reliable service and fast delivery
