- For fluxing and Pre heating PCB’s before soldering
- Carrier supplied compatible with Model DIP 905
- Manual carrier movement on conveyor rails
- Digital Temperature controller for pre-heater
| General | Dimensions in mm | L-775 W-525 H-375 |
| Weight | 20 Kg | |
|
Flux Bath & Air Knife |
Flux Bath Capacity | 4.0 ltrs |
| Foam Width | 14” | |
| Foam Height | 10mm | |
| Air Consumption | 40 cfm at 30psi | |
| Pre-Heater | Power Supply | 220 V AC, 50 Hz, 1.6 KW |
| Standard Accessories | PCB Carrier | 1 No |
| Utilities | Power Connection | 15 Amp Power Point |
| Air Supply | Compressed Air with FR |
